Active PFC and LLC techniques are applied for a rapid respond on a detected fault. Quick active software self-protection and reliable passive hardware self-protection on voltage & current. Advanced charging strategy is integrated as a safeguard for battery system protection.
- Features
- Specifications
- Warranty
Features
MINIMIZE DOWNTIME. MAXIMIZE PRODUCTIVITY.
SAFETY AND LONGEVITY
BUILT-IN PROTECTIONS COME STANDARD
- Burnout Protection
- No-load Protection
- Short Circuit Protection
- Automatic shutdown when fully charged
PROVEN RELIABILITY
Charging shell is shaped by integrated die casting and joined with temperature resistant glue. The active cooling fan is designed with a potting structure to provide longer life. Charger has been tested in various industrial environments (wet, cold, hot, dusty) and design is proven and passed for unmatched reliability
Rapid charge time is required to provide maximum productivity. That's why we are offering the 8kW super charging system to charge quickly and safely to get users back on the job faster than ever before.
Rapid charge time is required to provide maximum productivity.
That's why we are offering the 8kW
super charging system to charge quickly and safely to get users back on the job faster than ever before.
Specifications
TECHNICAL DATA
| Charge Rate (A) | AC 240V 31A (7.7kW) |
| Max Output Voltage | 86.4V |
| Outout Current | DC 80A |
| Rated Input Current | 32.0 A |
| Rated Input Power | 7.7 kVA |
| Charge Time | 24kWh Within 3hrs |
DIMENSIONS
| Length (in.) | 28.78" |
| Width (in.) | 18.74" |
| Height (in.) | 18.74" |
| Tool Weight | 88lbs |
Warranty
- 82v Commercial Handheld tools, battery, and chargers: 2-year limited warranty
- 82v Consumer/Prosumer lineup: 4-year limited warranty
- 24/48v warranty: 3-year limited warranty
- Commercial ZTR Warranty: 5-year or 2,000-hour warranty
- NEW residential/consumer warranty on our COMMERCIAL ZTRs: 7-year or 700-hour warranty
- Commercial UTV warranty: 5-year battery warranty, 2-year bumper to bumper warranty
- Wearable Parts: 60-day warranty
